产品名称： |
凸耳对夹式蝶阀 |
| 产品类别： |
美标阀门系列 → 美标蝶阀
|
| 产品性质： |
普通
|
| 点击次数： |
1866 |
| 资料下载： |
暂无下载
|
 |
|
产品详细介绍 |
·格规 主要尺寸
|
DN |
150Lb |
|
mm |
in |
L |
D1 |
D2 |
n-φd |
H |
H1 |
H2 |
|
50 |
2 |
43 |
120.7 |
92 |
4-φ19 |
345 |
280 |
110 |
|
80 |
3 |
49 |
152.4 |
127 |
4-φ19 |
380 |
315 |
125 |
|
100 |
4 |
56 |
190.5 |
157 |
8-φ19 |
415 |
350 |
145 |
|
125 |
5 |
64 |
216.0 |
186 |
8-φ22.5 |
455 |
390 |
165 |
|
150 |
6 |
70 |
241.3 |
216 |
8-φ22.5 |
545 |
455 |
175 |
|
200 |
8 |
71 |
298.5 |
270 |
8-φ22.5 |
615 |
522 |
210 |
|
250 |
10 |
76 |
362.0 |
324 |
12-φ25.4 |
695 |
605 |
250 |
|
300 |
12 |
86 |
431.8 |
381 |
12-φ25.4 |
830 |
730 |
285 |
|
350 |
14 |
92 |
476.3 |
413 |
12-φ29 |
900 |
800 |
320 |
|
400 |
16 |
102 |
539.8 |
470 |
16-φ29 |
980 |
870 |
355 |
|
450 |
18 |
114 |
577.9 |
533 |
16-φ32 |
1030 |
920 |
380 |
|
500 |
20 |
127 |
635 |
584 |
20-φ32 |
1110 |
1000 |
415 |
|
600 |
24 |
154 |
749.3 |
692 |
20-φ35 |
1305 |
1155 |
475 |
|
750 |
30 |
165 |
846 |
813 |
44-φ22.5 |
1525 |
1375 |
580 |
|
800 |
32 |
190 |
900 |
684 |
48-φ22.5 |
1585 |
1435 |
630 |
|
900 |
36 |
203 |
1009.7 |
972 |
44-φ25.4 |
1765 |
1585 |
680 |
|
1050 |
42 |
251 |
1171.5 |
1130 |
48-φ28.4 |
1871 |
1610 |
680 |
|
1200 |
48 |
276 |
1335 |
1289 |
44-φ32 |
2200 |
2120 |
680 |
|
300 Lb |
|
50 |
2 |
43 |
120.7 |
92 |
4-φ19 |
345 |
280 |
110 |
|
80 |
3 |
49 |
152.4 |
127 |
4-φ19 |
380 |
315 |
125 |
|
100 |
4 |
56 |
190.5 |
157 |
8-φ19 |
415 |
350 |
145 |
|
150 |
6 |
70 |
270 |
216 |
8-φ22.5 |
545 |
455 |
175 |
|
200 |
8 |
71 |
330 |
270 |
8-φ22.5 |
615 |
522 |
210 |
|
250 |
10 |
76 |
387 |
324 |
12-φ25.4 |
695 |
605 |
250 |
|
300 |
12 |
86 |
451 |
381 |
12-φ25.4 |
830 |
730 |
285 |
|
350 |
14 |
92 |
514 |
413 |
12-φ29 |
900 |
800 |
320 |
|
400 |
16 |
102 |
591 |
470 |
16-φ29 |
980 |
870 |
355 |
|
450 |
18 |
114 |
628 |
533 |
16-φ32 |
1030 |
920 |
380 |
|
500 |
20 |
127 |
686 |
584 |
20-φ23 |
1110 |
1000 |
415 |
|
600 |
24 |
154 |
813 |
692 |
20-φ35 |
1305 |
1155 |
475 |
|
750 |
30 |
165 |
997 |
857 |
44-φ22.5 |
1525 |
1375 |
580 |
|
900 |
36 |
203 |
1168 |
1022 |
44-φ25.4 |
1765 |
1585 |
680 |
|
1050 |
42 |
251 |
1171.5 |
1130 |
48-φ28.4 |
1871 |
1610 |
680 |
|
1200 |
48 |
276 |
1335 |
1289 |
44-φ32 |
2200 |
2120 |
680 | |
|
|
|
